Auralux Foam Mounting
Has anyone used the Auralex EZ-Stick Pro Mounting Tabs?
For years I've been struggling with adhering these panels - the regular cheap 2 X 4 panels - and foam bass traps - to walls and ceilings. I've tried the Auralux spray adhesive, Auralux caulking type adhesive, and other methods. They always strip away/fall off, however. The only success I've had is adhering them to thin particle boards and hanging those. But that method has limitations.
I'm looking for a new way. Just wondering if anyone has tried these tabs and, if so, whether they work. Alternative effective methods would be welcome as well!
As always, thank you in advance!
In other news, the Bakers are coming out with new features faster than I can learn them! 👍
|
Bristol_Jonesey
Max Output Level: 0 dBFS
- Total Posts : 16775
- Joined: 2007/10/08 15:41:17
- Location: Bristol, UK
- Status: offline
Re: Auralux Foam Mounting
2015/10/23 11:17:30
(permalink)
No More Nails Works perfectly
CbB, Platinum, 64 bit throughoutCustom built i7 3930, 32Gb RAM, 2 x 1Tb Internal HDD, 1 x 1TB system SSD (Win 7), 1 x 500Gb system SSD (Win 10), 2 x 1Tb External HDD's, Dual boot Win 7 & Win 10 64 Bit, Saffire Pro 26, ISA One, Adam P11A,
|
TerraSin
Max Output Level: -55.5 dBFS
- Total Posts : 1975
- Joined: 2005/08/05 00:27:13
- Location: USA
- Status: offline
Re: Auralux Foam Mounting
2015/10/23 13:11:01
(permalink)
I'm personally going to be mounting mine to particle board and hanging them with screws. I really don't like the idea of messing up my walls with adhesive. Especially if I decide to change the room up eventually.
|
tlw
Max Output Level: -49.5 dBFS
- Total Posts : 2567
- Joined: 2008/10/11 22:06:32
- Location: West Midlands, UK
- Status: offline
Re: Auralux Foam Mounting
2015/10/23 13:18:05
(permalink)
I glue the foam on sheets of heavy card or stiff corrugated card then use screws and wall plugs to space that an inch or two off the walls.
A very effective and cheaper alternative is to put heavy rockwool sheets in a timber frame, cover the lot with hessian to stop fibres escaping then space that off the walls.
Sonar Platinum 64bit, Windows 8.1 Pro 64bit, I7 3770K Ivybridge, 16GB Ram, Gigabyte Z77-D3H m/board, ATI 7750 graphics+ 1GB RAM, 2xIntel 520 series 220GB SSDs, 1 TB Samsung F3 + 1 TB WD HDDs, Seasonic fanless 460W psu, RME Fireface UFX, Focusrite Octopre. Assorted real synths, guitars, mandolins, diatonic accordions, percussion, fx and other stuff.
|
bitman
Max Output Level: -34 dBFS
- Total Posts : 4105
- Joined: 2003/11/06 14:11:54
- Location: Keystone Colorado
- Status: offline
Re: Auralux Foam Mounting
2015/10/23 14:02:40
(permalink)
|
Jesse G
Max Output Level: -32.5 dBFS
- Total Posts : 4282
- Joined: 2004/04/14 01:43:43
- Status: offline
Re: Auralux Foam Mounting
2015/10/23 15:43:18
(permalink)
I like to use the 3M "Large Picture Hanging Strips". They work well when you add one to each corner, also they can be removed or moved to other locations.
Peace,Jesse G. A fisher of men <>< ==============================Cakewalk and I are going places together! Cakewalk By Bandlab, Windows 10 Pro- 64 bit, Gigabyte GA-Z97X-SLI, Intel Core i5-4460 Haswell Processor, Crucial Ballistix 32 GB Ram, PNY GeForce GTX 750, Roland Octa-Capture, Mackie Big Knob, Mackie Universal Controller (MCU), KRK V4's, KRK Rockit 6, Korg TR-61 Workstation, M-Audio Code 49 MIDI keyboard controller.[/
|
MandolinPicker
Max Output Level: -76 dBFS
- Total Posts : 720
- Joined: 2003/11/05 18:51:51
- Location: Oxford, AL
- Status: offline
Re: Auralux Foam Mounting
2015/10/23 16:11:14
(permalink)
The Mandolin Picker "Bless your hearts... and all your vital organs" - John Duffy "Got time to breath, got time for music!"- Briscoe Darling, Jr. Windows 8.1, Sonar Platinum (64-bit), AMD FX 6120 Six-Core, 10GB RAM
|
Treefight
Max Output Level: -73 dBFS
- Total Posts : 868
- Joined: 2007/11/23 15:57:41
- Location: Boston
- Status: offline
Re: Auralux Foam Mounting
2015/10/23 16:15:40
(permalink)
Thanks, all. Weird - I've used the 3M strips as well, but they don't stick very well to the foam (for me, at least).
Anyhow, glad to hear the Auralux tabs work. I do like mounting them on card - a couple times I've then wrapped the square in a funky cloth, like tie dye. I wonder if that negatively impacts the absorption (?)
I've been considering the rockwool/wood frame option for a while - is it difficult to make? I'm not particularly handy. I did make three so-called "BBC" diffusers a couple of years ago. I read about making them in one of the pro audio mags. They made it sound so easy. Actually, it WAS easy, but it took many many hours when all the measuring, cutting, gluing, and painting was done.
The real killer for me is getting bass traps to stick on a wall/ceiling corner, especially when the ceiling is somewhat textured (not sure what you'd call it, looks sort of like plaster). Obviously flat is better, but still, I've tried everything.
Actually, that raises the question of whether the tabs will work on my ceiling with the panels, given that the ceiling isn't perfectly flat (?).
I'll post a picture of the ceiling when I get home and I'd love to hear your thoughts on the matter. Another issue is that an air shaft is behind the ceiling above my work station so any kind of hardware is out. I know, poor planning, but rearranging my entire studio is not an option (well, I suppose it could be, but... Ugh).
Thanks again for the helpful replies.
|
bitflipper
01100010 01101001 01110100 01100110 01101100 01101
- Total Posts : 26036
- Joined: 2006/09/17 11:23:23
- Location: Everett, WA USA
- Status: offline
Re: Auralux Foam Mounting
2015/10/23 16:16:36
(permalink)
If you glue them onto 1" deep wooden frames, you'll actually be enhancing their effectiveness, cutting the lowest frequency they're effective at in half. That's for the thin pieces only, does not apply to corner traps.
All else is in doubt, so this is the truth I cling to. My Stuff
|
Bristol_Jonesey
Max Output Level: 0 dBFS
- Total Posts : 16775
- Joined: 2007/10/08 15:41:17
- Location: Bristol, UK
- Status: offline
Re: Auralux Foam Mounting
2015/10/23 16:17:17
(permalink)
tlw A very effective and cheaper alternative is to put heavy rockwool sheets in a timber frame, cover the lot with hessian to stop fibres escaping then space that off the walls.
Yep. I've got a few of them set up as well as a load of tiles. It's really not bad for a 12 ft x 12 ft room!
CbB, Platinum, 64 bit throughoutCustom built i7 3930, 32Gb RAM, 2 x 1Tb Internal HDD, 1 x 1TB system SSD (Win 7), 1 x 500Gb system SSD (Win 10), 2 x 1Tb External HDD's, Dual boot Win 7 & Win 10 64 Bit, Saffire Pro 26, ISA One, Adam P11A,
|
Treefight
Max Output Level: -73 dBFS
- Total Posts : 868
- Joined: 2007/11/23 15:57:41
- Location: Boston
- Status: offline
Re: Auralux Foam Mounting
2015/10/23 16:17:35
(permalink)
Hmmm... The T-pins might be a good option for the bass traps (avoiding the air shaft, of course).
|
Treefight
Max Output Level: -73 dBFS
- Total Posts : 868
- Joined: 2007/11/23 15:57:41
- Location: Boston
- Status: offline
Re: Auralux Foam Mounting
2015/10/23 16:19:35
(permalink)
Ok, so actual frames, not just boards, i.e., with some depth to them?
|
Treefight
Max Output Level: -73 dBFS
- Total Posts : 868
- Joined: 2007/11/23 15:57:41
- Location: Boston
- Status: offline
Re: Auralux Foam Mounting
2015/10/23 16:24:11
(permalink)
It seems to me the easiest option would be to just have someone with scientific knowledge of acoustics and all that come over and just tell me what needs to go where. Bitflipper, what are you doing this weekend?
|
bitflipper
01100010 01101001 01110100 01100110 01101100 01101
- Total Posts : 26036
- Joined: 2006/09/17 11:23:23
- Location: Everett, WA USA
- Status: offline
Re: Auralux Foam Mounting
2015/10/23 16:45:35
(permalink)
Sorry, too far to drive. But I'll gladly supply this tip free of charge: more than half of everything I know about acoustics I learned from this one book:
All else is in doubt, so this is the truth I cling to. My Stuff
|
Treefight
Max Output Level: -73 dBFS
- Total Posts : 868
- Joined: 2007/11/23 15:57:41
- Location: Boston
- Status: offline
Re: Auralux Foam Mounting
2015/10/23 17:37:12
(permalink)
|
townstra
Max Output Level: -88 dBFS
- Total Posts : 118
- Joined: 2013/10/09 18:25:53
- Location: Denton, TX
- Status: offline
Re: Auralux Foam Mounting
2015/10/24 14:08:05
(permalink)
I used them and they didn't work all that well for me. Some of them didn't want to stick very well and I had to do some remounting. It could have to do with the paint finish on my wall.
Regards, Tracy Sonar Platinum, Harrison Mixbus 4, Melodyne 4 Studio, Slate Digital FG-X, ARC 2, Windows 10 Pro x64, Intel I7-4790@3.6ghz, 16 Gb RAM, GeForce GT730, Focusrite Scarlett 18i20, Behringer ADA8200, Prodipe Ribbon 8 monitors, Prodipe Pro5 monitors, Behringer B2030P monitors, Korg nanokontrol, Korg microKey, Samson Graphite MF8, rack full of channel strips and processors, lots of guitars, basses, and pedals. www.TracyTowns.com
|
